Trucks All models Heavy Truck Howo TX 430 6x4 Tractor Truck

Howo TX 430 6x4 Tractor Truck

Howo TX 430 6x4 Tractor Truck can be adapted to 60-70-ton semi-trailers and performs well in scenarios such as port container transportation and long-distance transportation of bulk goods.

Models

Drive type: 6x4

Engine: Sinotruk MC11.43-30

Maximum Horsepower: 430hp

Transmission: Sinotruk HW25716XAL

Fuel tank capacity: 600L

Request a Quote WhatsApp

Product Description

Application

HOWO TX 430 6x4 Tractor Truck is a high-performance tractor truck built by Sinotruk for heavy-duty logistics transportation.

Features

HOWO TX 430 6×4 Tractor Truck is equipped with a 430-horsepower engine and a 6×4 all-wheel drive chassis design.

HOWO TX 430 6×4 Tractor Truck is equipped with a power system that meets the Euro II emission standards, and is equipped with a reinforced beam and air suspension system to ensure the stability and durability of the vehicle under heavy-load conditions. The cab of HOWO TX 430 6×4 Tractor Truck provides two configurations: left-hand drive and right-hand drive to meet the regulatory requirements of different regions. It integrates a multi-function steering wheel and an intelligent instrument panel to improve operational convenience.

Model		Howo TX 430 6×4 Tractor Truck
Chassis Model		ZZ4257V324GB1R
Drive type		6×4
Kerb Weight(kg)		8960
GCW(kg)		50000
Dimensions LxWxH(mm)		6800×2500×3225
Wheelbase(mm)		3200
Cabin	Model	TX-F
Engine	Model	MC11.43-30
	Horse Power(Hp)	430
	Maximum torque(N ·m/rpm)	1500N ·m/1050-1400rpm
	Rated power(kW/rpm)	319kW/1900rpm
	Emission	Euro Ⅲ
	Displacement	11 L
Transmission	Model	HW25716XAL
	TYPE	Manual-Automatic
	Gear position	14 forwards &2 reverses
AXLE	Front axle Load capacity(kg)	VGD71 (Drum) 7100
	rear axle Load capacity(kg)	MCJ12BGY 12000×2
	Ratio	3.70
Chassis	Thinkness(mm)	8/280
Suspension	Type	Leaf springs(3/5)
Steering	Model	Bosch
Fifth Wheel	Model	2.5 inch
Fuel tank capacity	Volume(L)	600
Tire	Mode	12.00R24,315/80R22.5

Performance

HOWO TX 430 6x4 Tractor Truck adopts a modular design concept, and the engine maintenance cycle reaches 100,000 kilometers, effectively reducing operating costs.

SINOTRUK's Exclusive High-End Power

Experience more power with less fuel: Employing the most advanced BOSCH high-pressure common rail system, the ECU precisely controls the fuel injection process according to the engine’s operating state, achieving a maximum injection pressure of 1600 bar to ensure superior fuel atomization, increased engine power, and reduced fuel consumption.

Transmission - Always in the Right Gear

The HW series transmission incorporates a globally advanced transmission design, employing a double countershaft main transmission coupled with a planetary gear auxiliary transmission.

Axles - Carry More, Cost Less

The MC series drive axles and V series steering axles are engineered based on advanced German axle technology and improved with the latest technical standards, offering higher transmission efficiency, superior heat dissipation, increased load capacity, and extended service life to accommodate various road conditions.

All-Around Vision, Everything in Sight

Featuring wide-view design, four-way monitoring system (optional), and observation window (optional), the driver is accessible to comprehensive visual information about the surrounding environment and traffic dynamics of the vehicle, thus making accurate assessments, and safely responding to various situations.

High Comfort

Featuring an adjustable air suspension seat, the HOWO-TX offers multi-directional electric adjustment and lumbar support, allowing drivers to personalize their seating for optimal comfort. Crafted from high-quality, breathable materials, the seat effectively reduces fatigue during long drives.

Gallery

With its 25-45 ton traction capacity and efficient fuel economy, this HOWO TX 430 6x4 Tractor Truck has become the preferred equipment in the field of international logistics and transportation.
