Trucks All models Heavy Truck Howo 7 8x4 Dump Truck

Howo 7 8x4 Dump Truck

Howo 7 8x4 Dump Truck is a high-performance truck designed for heavy-duty transportation, widely used in construction, mining and infrastructure construction.

Models

Drive type: 8x4

Engine: MC11.44-50

Maximum horsepower: 340hp

Maximum speed: 90 km/h

Fuel tank capacity: 400L

Request a Quote WhatsApp

Product Description

Application

HOWO-7: Fully Equipped to Face the Toughest Working Conditions

Features

With its powerful power system and excellent carrying capacity, Howo 7 8×4 Dump Truck can easily cope with various complex transportation tasks.

In addition, the suspension system and brake system of Howo 7 8×4 Dump Truck are carefully designed to ensure safety and comfort under heavy load conditions. Howo 7 8×4 Dump Truck’s powerful engine not only provides excellent performance, but also has good fuel economy, reducing operating costs.

In short, Howo 7 8×4 Dump Truck has become an indispensable tool in the heavy transport industry with its excellent performance and reliability, helping users to complete various transport tasks efficiently.

Howo 7 8×4 Dump Truck Specifications

Dump truck basic	Made	SINOTRUK
	Series	HOWO
	Howo dump Model	ZZ3317N3567
	Howo dump Driving Type	8×4
Howo dump Engine	Howo dump Engine model	WD615.47
	Howo dump Engine Type	6-cylinder in-line with water cooling, turbo-charging and intercooling,4-stroke direct injection diesel engine
	Howo dump Maximum output	371 hp (247 Kw) at 2200 rpm
	Howo dump Displacement	9.726 L
	Bore	126 mm
	Stroke	130 mm
	Compression ratio	29.8 hp/l
	Specific fuel consumption	195 g/kWh
Howo dumpTransmission	Model	HW15710(Fuller technology)
Howo dumpTransmission	speeds	10 speeds
Howo dump Axle	Front Axle	9T
Howo dump Axle	Rear Axle	16T
Howo dump Fuel tank	Aluminium fuel tank	300 L capacity with locking fuel cap
Howo dump Steering	Model	power steering, modol 8098, hydraulic steering
Howo dump Tyre	Radial Tyre	12.00R20
Howo dump Driver’s Cab	Flat roof cab with bed	all steal forward control,2-arm windscreen wiper system with three speed,laminated windscreen, damped adjustable driver’s seat, with heating and ventilating system, adjustable steering wheel,air conditioner
Howo dump Dimensions mm	Wheel base	3600+1350
	Overall dimmensions	1024524963386
	Dimension of the rear dump body	730023001500MM
Howo dump Performance	Maximum driving speed (km/h)	75
	Maximum gradeability (%)	40
	Minimum ground clearance (mm)	314
	Minimum turning circle (m)	20
	Fuel consumption (l/100 km)	28

Performance

Howo 7 8x4 Dump Truck has a large cabin capacity and can load more materials, greatly improving transportation efficiency. Whether it is sand, earth or other heavy materials, Howo 7 8x4 Dump Truck can handle it easily.

Air Suspension Seat

The air suspension seat allows drivers to quickly find the optimal sitting position. The integrated design of the seat belt and the seat is ergonomically compliant, avoiding the driver's feeling of suffocation caused by emergency braking during driving.

Four-Point Air Suspension

The four-point air suspension provides excellent stability, shock absorption, and comfort, and features a cabin rearward displacement function during collisions, ensuring passenger safety.

Safe Driving Cabin

The cabin's body is constructed with a one-piece steel frame, providing robust strength, rigidity, and superior resistance to impacts and external forces. Its safety performance has been proven through stringent crash testing.

Engine

Utilizing WD615/D10 series and WP10/WP12 series powertrains, the vehicle offers high torque at low speeds and strong power. Parts are highly interchangeable within the same engine series, leading to low maintenance costs and easy repairs. Horsepower range covers 266-430Ps, and emissions cover Euro 2-Euro 5.

Transmission

Utilizing HW series 10-speed/12-speed transmissions, the transmission adopts a main and auxiliary box structure, the main box is a double countershaft structure, and the auxiliary box is a planetary reduction structure, with strong bearing capacity and reliable structure.

Gallery

The 8x4 drive configuration of this Howo 7 8x4 Dump Truck provides excellent traction and stability, allowing it to perform well on rugged terrain.
