Trucks All models Heavy Truck Howo 7 6x4 Dump Truck

Howo 7 6x4 Dump Truck

The HOWO-7 truck excels in challenging environments like construction sites and mines, thanks to its strength, ruggedness, and durability.In harsh working environments, HOWO-7 is fully equipped to face the toughest working conditions.

Models

Drive type: 6x4

Engine: MC11.44-50

Maximum horsepower: 340hp

Maximum speed: 90 km/h

Fuel tank capacity: 400L

Request a Quote WhatsApp

Product Description

Application

HOWO-7: Fully Equipped to Face the Toughest Working Conditions

Features

The 6×4 drive system of this Howo 7 6×4 Dump Truck provides excellent traction, allowing it to drive stably on rugged roads. The cabin of Howo 7 6×4 Dump Truck is reasonably designed to accommodate a large amount of cargo, greatly improving transportation efficiency. In addition, the suspension system and brake system of Howo 7 6×4 Dump Truck are carefully designed to ensure safety and comfort under heavy loads.

In terms of maintenance, Howo 7 6×4 Dump Truck has a simple structure, is easy to maintain, and reduces operating costs.

Howo 7 6×4 Dump Truck Specifications

Brand: Howo	Strain: 7	Substrain:7
Vehicle category: Medium and heavy trucks+A3:C14	Vehicle use: Tipper, Dump Truck	Drive type: 8×4/6×4
Total mass (t):25/31	Overall mass (kg):10100/11200	Wheelbase (mm):3500/3825
Vehicle length (mm):10400/8500	Vehicle width (mm):2550	Vehicle height (mm):3350/3450
Truck Model: ZZ3317V3567B1R/ZZ3257N3847B1R
Engine: WP12.400E201 engine	Engine power (Ps):380	Emission level: Euro II
Cab: HW76 new front cab	Transmission: HW19710 gearbox + HW50 power take-off(PTO)
Frame: Double layer frame (8+8/300)	Front axle: VGD95 front axle (Drum)	Drive Axle: MCP16ZG Dual Rear Axle (Drum)
Drive axle speed ratio: 5.92/5.26	Steering gear: Bosch steering gear	Brake control system: with ABS
Bumper: High bumper (Full metal)		Fuel tank/gas cylinder: 300L fuel tank
Tyres: 12.00R20 tyres (mixed tread/20PR)
Here are the specifications for the Howo 7 Dump Truck configuration you mentioned: Type: Tipper Truck, Large Truck for road transport Cab: HW76 new front cab Engine: WP12.400E201 Transmission: HW19710 gearbox + HW50 direct-connected power take-off (PTO) Front Axle (Drum): VGD95 Rear Axle (Drum): MCP16ZG dual Frame: Double-deck (8+8/300) Suspension: Front and rear reinforced multi-leaf springs (11/11/12) Steering: Bosch steering wheel Exhaust System: Standard with ABS Bumper: High-level all-metal Seats: Main mechanical + sub-lightweight Speed Ratio: 5.92 Intake System: Engineered air intake (Oil Bath Filter) Wheels: 12.00R20 (mixed tread/20PR) Fuel Tank: 300L Optional Features: Rear towing hitch, fire extinguisher, optional reversing buzzer, optional under-vehicle start-stop switch, metal bumpers with front and rear light protectors, cold and warm air conditioning Dashboard: English and French These specifications highlight the capabilities and features of the Howo 7 Dump Truck, suitable for various road transport and heavy-duty applications.
☆Made to order: We offer customized truck specifications to suit your requirements!

Performance

Howo 7 6x4 Dump Truck is a heavy-duty truck widely used in the construction and mining fields. Howo 7 6x4 Dump Truck is known for its powerful performance and reliable durability.

Air Suspension Seat

The air suspension seat allows drivers to quickly find the optimal sitting position. The integrated design of the seat belt and the seat is ergonomically compliant, avoiding the driver's feeling of suffocation caused by emergency braking during driving.

Four-Point Air Suspension

The four-point air suspension provides excellent stability, shock absorption, and comfort, and features a cabin rearward displacement function during collisions, ensuring passenger safety.

Safe Driving Cabin

The cabin's body is constructed with a one-piece steel frame, providing robust strength, rigidity, and superior resistance to impacts and external forces. Its safety performance has been proven through stringent crash testing.

Engine

Utilizing WD615/D10 series and WP10/WP12 series powertrains, the vehicle offers high torque at low speeds and strong power. Parts are highly interchangeable within the same engine series, leading to low maintenance costs and easy repairs. Horsepower range covers 266-430Ps, and emissions cover Euro 2-Euro 5.

Transmission

Utilizing HW series 10-speed/12-speed transmissions, the transmission adopts a main and auxiliary box structure, the main box is a double countershaft structure, and the auxiliary box is a planetary reduction structure, with strong bearing capacity and reliable structure.

Gallery

Whether in urban construction or mining operations, Howo 7 6x4 Dump Truck is a trustworthy choice to help users complete various tasks efficiently.
